AP4C detector

M910 SERIES

Excellence in CBRN threat management

The AP4C is a combat proven flame spectrometer detector with industry leading capabilities that is used worldwide in over 75 countries and counting.
It can detect a broad range of conventional and detect a broad range of conventional and unconventional threats.
Designed for field use, the AP4C takes the complexity out of the equation: one single ON/OFF button, no settings or menu, no field calibration and filter.
The entire detection process is completely automatic.
Thanks to its unique technology, the AP4C has the shortest recovery time even after being exposed to high concentration of chemicals.
AP4C has the highest user availability rate on the market.
An annual check is the only required maintenance operation.
No need to regularly start the detector to keep it operational.

Application

  • Military Forces
  • First responders
  • Law enforcement
  • CBRN specialists
  • HazMat teams
  • Customs and border protection

Detection

  • All nerve agents
  • All blister agents
  • All blood agents
  • All NTA such as Novickok
  • Choking agents
  • Numerous toxic industrials
  • PBA (such as fentanyl) and opioids under solid, liquid or gas forms.

Content

  • Each set comes ready to use with all accessories and consumables neatly packed in a waterproof Pelican case.

Kit options

  • UC AP4C (M910 E00 003) : standard kit with S4PE liquid sampler and extra consumables.
    UC AP4C MleF1 (M910 E00 001) : extended AP4C kit with two S4PE and additional consumables.
    AP4C X (M910 E00 00X): standard kit with the addition of a S4PF sampler for opioids / fentanyl detection.
    AP4C set (M910 E00 002): low cost option, comes with the AP4C without S4PE or consumables.

Accessories & services

  • SimToolKit (M2852 E00 000): wireless system for monitoring and training, connects up to 8 detectors
  • Minibench (M2417 E00 000): refill station for hydrogen cylinders
  • Prepaid maintenance and extended warranty options available upon initial acquisition
  • For training, technical support or maintenance, contact us at contact@proengin.com

Specifications

  • Technology: SimToolKit (M2852 E00 000): wireless system for monitoring and training, connects up to 8 detectors

    Minibench (M2417 E00 000): refill station for hydrogen cylinders

    Prepaid maintenance and extended warranty options available upon initial acquisition

    For training, technical support or maintenance, contact us at contact@proengin.com

  • Detection range: Unlimited, CWA, TICs & TIMS, NTAs, Novichoks, binaries, opioids & Fentanyl
  • Operating temperature: -25°F to +122°F / -32°C to +50°C
  • Data storage: Internal memory, 530 hours loop recording
  • Powers supply: Lithium or rechargeable battery
  • Height: 138mm
  • Length: 385mm
  • Width: 100mm
  • Weight: 2
